.gitignore

-paper.html
-paper.pdf
 img/git-remote-contributor.svg
 img/git-remote-maintainer.svg
 img/git-remote-solo.svg
 img/license-chooser.svg
+img/motivation-structure.svg
 img/motivation-throwaway-playground.svg
+img/rdm-use-case-data.svg
+img/rdm-use-cases-a.svg
+img/rdm-use-cases-b.svg
+img/rdm-use-cases.svg
 img/staging-area.svg
+paper.html
+paper.pdf
 *.pdf
+img/staging-area-diff.svg
+/img/rdm-use-case-merged.svg

.gitmodules

 [submodule "reveal.js"]
 	path = reveal.js
 	url = https://github.com/hakimel/reveal.js.git
+[submodule "pandoc-cheat-sheet"]
+	path = pandoc-cheat-sheet
+	url = https://github.com/idiv-biodiversity/pandoc-cheat-sheet.git

Makefile

@@ -17,12 +17,22 @@ pandoc-papers.pdf: pandoc-papers.md
 		-o pandoc-papers.pdf \
 		pandoc-papers.md

+rdm.pdf: img rdm.md rdm.yml
+	pandoc \
+		--standalone \
+		--from=markdown+yaml_metadata_block \
+		--pdf-engine=xelatex \
+		--template=pandoc-cheat-sheet/cheat-sheet.tex \
+		-o rdm.pdf \
+		rdm.yml rdm.md
+
 all: subdirs

 clean:
 	for dir in $(SUBDIRS); do \
 	  $(MAKE) -C $$dir $@; \
 	done
+	rm -f rdm.pdf

 default: all


advanced.md

+# regular FAQ
+
+- 10-12 git integration RStudio / VS Code / others
+- 13-15 GitLab / GitHub project setup / importing existing projects / how to start and continue after that, project management, issue management
+- 15-16 GitLab / GitHub automation
+- 16-18 free for all
+
 # git advanced -- how to maintain a comprehensible history

 - when projects get bigger

img/git-remote-contributor.dot

@@ -6,7 +6,7 @@ digraph {

         node [color = orchid]

-        omaster[label = "master"]
+        omain[label = "main"]
     }

     subgraph clusterlocal {
@@ -14,7 +14,7 @@ digraph {

         node [color = orchid]

-        master[label = "master"]
+        main[label = "main"]
     }

     subgraph clusterupstream {
@@ -22,11 +22,11 @@ digraph {

         node [color = limegreen]

-        umaster[label = "master"]
+        umain[label = "main"]
     }

-    omaster -> master [label = "git pull"]
-    master -> omaster [label = "git push", constraint = false]
-    umaster -> master [label = "git pull upstream master", constraint = false]
-    omaster -> umaster [label = "pull request (GitHub)\nmerge request (GitLab)", constraint = false]
+    omain -> main [label = "git pull"]
+    main -> omain [label = "git push", constraint = false]
+    umain -> main [label = "git pull upstream main", constraint = false]
+    omain -> umain [label = "pull request (GitHub)\nmerge request (GitLab)", constraint = false]
 }

img/git-remote-maintainer.dot

@@ -6,7 +6,7 @@ digraph {

         node [color = orchid]

-        omaster[label = "master"]
+        omain[label = "main"]
     }

     subgraph clusterlocal {
@@ -14,7 +14,7 @@ digraph {

         node [color = orchid]

-        master[label = "master"]
+        main[label = "main"]
     }

     subgraph clusteralice {
@@ -22,7 +22,7 @@ digraph {

         node [color = limegreen]

-        amaster[label = "master"]
+        amain[label = "main"]
     }

     subgraph clusterbob {
@@ -30,11 +30,11 @@ digraph {

         node [color = lightskyblue]

-        bmaster[label = "master"]
+        bmain[label = "main"]
     }

-    omaster -> master [label = "git pull"]
-    master -> omaster [label = "git push", constraint = false]
-    amaster -> master [label = "git pull alice", constraint = false]
-    bmaster -> master [label = "git pull bob", constraint = false]
+    omain -> main [label = "git pull"]
+    main -> omain [label = "git push", constraint = false]
+    amain -> main [label = "git pull alice", constraint = false]
+    bmain -> main [label = "git pull bob", constraint = false]
 }

img/git-remote-solo.dot

@@ -9,7 +9,7 @@ digraph {

         node [color = orchid]

-        omaster[label = "master"]
+        omain[label = "main"]
     }

     subgraph clusterlocal {
@@ -17,10 +17,10 @@ digraph {

         node [color = orchid]

-        master[label = "master"]
+        main[label = "main"]
     }

-    omaster -> master [label = "git fetch", style = dotted, ltail = clusterorigin, lhead = clusterlocal]
-    master -> omaster [label = "git push"]
-    omaster -> master [label = "git pull"]
+    omain -> main [label = "git fetch", style = dotted, ltail = clusterorigin, lhead = clusterlocal]
+    main -> omain [label = "git push"]
+    omain -> main [label = "git pull"]
 }

img/motivation-structure.dot

+digraph {
+    node [shape = "box", style = "filled, rounded"]
+
+    master4[label = "Alice (today)\nfixes logic error", color = limegreen]
+    master3[label = "Bob (yesterday)\nfixes typos", color = darkorchid1]
+    master2[label = "Alice (three days ago)\nadds methods chapter", color = limegreen]
+    master1[label = "...", color = grey]
+
+    master4 -> master3 -> master2 -> master1
+}

img/motivation-throwaway-playground.dot

 digraph {
     node [shape = "box", style = "filled, rounded"]

-    subgraph clustermaster {
-        label = "master"
+    subgraph clustermain {
+        label = "main"

         node [color = limegreen]

-        master3[label = "ebe0262"]
-        master2[label = "03f4f8d"]
-        master1[label = "62a0ee9"]
+        main3[label = "..."]
+        main2[label = "..."]
+        main1[label = "..."]

-        master3 -> master2 -> master1
+        main3 -> main2 -> main1
     }

     subgraph clusterplayground {
@@ -18,11 +18,11 @@ digraph {

         node [color = orchid]

-        playground2[label = "8b29f74"]
-        playground1[label = "7f295dd"]
+        playground2[label = "visualization"]
+        playground1[label = "methods"]

         playground2 -> playground1
     }

-    playground1 -> master2
+    playground1 -> main2
 }

img/rdm-use-case-data.dot

+digraph {
+    compound = true
+    node [shape = "box", style = "filled, rounded"]
+
+    subgraph cluster_script {
+        label = "scripts"
+
+        node [color = lightskyblue]
+
+        script_version_b[label = "nature-v2"]
+    }
+
+    subgraph cluster_data {
+        label = "data repository (not git!)"
+
+        node [color = limegreen]
+
+        data_version_a[label = "doi:blah/blah"]
+    }
+
+    subgraph cluster_paper {
+        label = "paper"
+
+        node [color = limegreen]
+
+        paper_version_c[label = "nature-final"]
+    }
+
+    paper_version_c -> data_version_a [label = "\n\n", lhead = cluster_data]
+
+    data_version_a -> script_version_b [label = "\n\n", lhead = cluster_script]
+}

img/rdm-use-case-merged.dot

+digraph {
+    compound = true
+    node [shape = "box", style = "filled, rounded"]
+
+    subgraph cluster_script {
+        label = "scripts"
+
+        node [color = lightskyblue]
+
+        script_version_b[label = "nature-v2"]
+        script_version_a[label = "nature-v1"]
+    }
+
+    subgraph cluster_data {
+        label = "data repository (not git!)"
+
+        node [color = limegreen]
+
+        data_version_a[label = "doi:blah/blah"]
+    }
+
+    subgraph cluster_paper {
+        label = "paper"
+
+        node [color = limegreen]
+
+        paper_version_a[label = "nature-review-1"]
+        paper_version_b[label = "nature-review-2"]
+        paper_version_c[label = "nature-final"]
+    }
+
+    subgraph cluster_software_a {
+        label = "software A"
+
+        node [color = orchid]
+
+        software_a_version_a[label = "v2.1.6"]
+    }
+
+    subgraph cluster_software_b {
+        label = "software B"
+
+        node [color = orchid]
+
+        software_b_version_b[label = "v0.3.4"]
+        software_b_version_a[label = "v0.2.0"]
+    }
+
+    script_version_a -> software_a_version_a [label = "\n\n"]
+    script_version_b -> software_a_version_a [label = "\n\n"]
+
+    script_version_a -> software_b_version_a [label = "\n\n"]
+    script_version_b -> software_b_version_b [label = "\n\n"]
+
+    paper_version_a -> script_version_a [label = "\n\n"]
+    paper_version_b -> script_version_b [label = "\n\n"]
+    paper_version_c -> script_version_b [label = "\n\n"]
+
+    paper_version_c -> data_version_a [label = "\n\n"]
+
+    data_version_a -> script_version_b [label = "\n\n"]
+
+}

img/rdm-use-cases-a.dot

+digraph {
+    compound = true
+    node [shape = "box", style = "filled, rounded"]
+
+    subgraph cluster_software_a {
+        label = "software A"
+
+        node [color = orchid]
+
+        software_a_version_a[label = "v2.1.6"]
+    }
+
+    subgraph cluster_software_b {
+        label = "software B"
+
+        node [color = orchid]
+
+        software_b_version_a[label = "v0.2.0"]
+    }
+
+    subgraph cluster_script {
+        label = "scripts"
+
+        node [color = lightskyblue]
+
+        script_version_a[label = "nature-v1"]
+    }
+
+    subgraph cluster_paper {
+        label = "paper"
+
+        node [color = limegreen]
+
+        paper_version_a[label = "nature-review-1"]
+    }
+
+    script_version_a -> software_a_version_a [label = "\n\n"]
+
+    script_version_a -> software_b_version_a [label = "\n\n"]
+
+    paper_version_a -> script_version_a [label = "\n\n"]
+}

img/rdm-use-cases-b.dot

+digraph {
+    compound = true
+    node [shape = "box", style = "filled, rounded"]
+
+    subgraph cluster_software_a {
+        label = "software A"
+
+        node [color = orchid]
+
+        software_a_version_a[label = "v2.1.6"]
+    }
+
+    subgraph cluster_software_b {
+        label = "software B"
+
+        node [color = orchid]
+
+        software_b_version_b[label = "v0.3.4"]
+        software_b_version_a[label = "v0.2.0"]
+    }
+
+    subgraph cluster_script {
+        label = "scripts"
+
+        node [color = lightskyblue]
+
+        script_version_b[label = "nature-v2"]
+        script_version_a[label = "nature-v1"]
+    }
+
+    subgraph cluster_paper {
+        label = "paper"
+
+        node [color = limegreen]
+
+        paper_version_a[label = "nature-review-1"]
+        paper_version_b[label = "nature-review-2"]
+    }
+
+    script_version_a -> software_a_version_a [label = "\n\n"]
+    script_version_b -> software_a_version_a [label = "\n\n"]
+
+    script_version_a -> software_b_version_a [label = "\n\n"]
+    script_version_b -> software_b_version_b [label = "\n\n"]
+
+    paper_version_a -> script_version_a [label = "\n\n"]
+    paper_version_b -> script_version_b [label = "\n\n"]
+}

img/rdm-use-cases.dot

+digraph {
+    compound = true
+    node [shape = "box", style = "filled, rounded"]
+
+    subgraph cluster_software_a {
+        label = "software A"
+
+        node [color = orchid]
+
+        software_a_version_a[label = "v2.1.6"]
+    }
+
+    subgraph cluster_software_b {
+        label = "software B"
+
+        node [color = orchid]
+
+        software_b_version_b[label = "v0.3.4"]
+        software_b_version_a[label = "v0.2.0"]
+    }
+
+    subgraph cluster_script {
+        label = "scripts"
+
+        node [color = lightskyblue]
+
+        script_version_b[label = "nature-v2"]
+        script_version_a[label = "nature-v1"]
+    }
+
+    subgraph cluster_paper {
+        label = "paper"
+
+        node [color = limegreen]
+
+        paper_version_a[label = "nature-review-1"]
+        paper_version_b[label = "nature-review-2"]
+        paper_version_c[label = "nature-final"]
+    }
+
+    script_version_a -> software_a_version_a [label = "\n\n"]
+    script_version_b -> software_a_version_a [label = "\n\n"]
+
+    script_version_a -> software_b_version_a [label = "\n\n"]
+    script_version_b -> software_b_version_b [label = "\n\n"]
+
+    paper_version_a -> script_version_a [label = "\n\n"]
+    paper_version_b -> script_version_b [label = "\n\n"]
+    paper_version_c -> script_version_b [label = "\n\n"]
+}

img/staging-area-diff.dot

+digraph {
+    node [shape = "box", style = "filled,rounded"]
+
+    workdir[label = "working directory\n(changes not staged for commit)", color = lightskyblue]
+    stage[label = "staging area\n(changes to be committed)", color = orchid]
+    repo[label = "repository\n(tracked content)", color = limegreen]
+
+    workdir -> stage [label = "git diff"]
+    stage -> repo [label = "git diff --staged"]
+}

pandoc-cheat-sheet @ 2346a002

+Subproject commit 2346a002289757ee612bfd4b56b57db53e0c751b
